Dry film lubricant coatings provide lubrication where liquid oils can’t be retained — high temperatures, vacuum, clean rooms, or where relubrication is impractical. MoS2, WS2, and hBN are the three primary solid lubricants used in these coatings.
What Is a Dry Film Lubricant Coating?
A thin layer (5–25 µm) of solid lubricant particles in a binder, applied to metal or ceramic surfaces. The coating lubricates through solid-particle shear rather than a liquid film.
Types:
- Resin-bonded (epoxy, phenolic, polyimide binder — spray or dip applied, then cured)
- Burnished (particles mechanically burnished onto surface, no binder)
- PVD/sputtered (vacuum-deposited thin films, <1 µm)
MoS2 Coatings — Best for Defense, Automotive, Industrial
Gun mechanisms, bolt carriers, fasteners, molds, piston skirts. Typical particle size: 0.5–3 µm. Treat rate: 15–40% solids. Best binders: epoxy-phenolic, polyimide. Max service temp: 350°C in air. Powderful Solutions supplies surface-modified MoS2 optimized for uniform dispersion in both solvent-based and waterborne coating systems.
WS2 Coatings — Best for Aerospace, Precision, High-Temp
PVD coatings on cutting tools, bearings, satellite components. Burnished onto precision parts for ultra-thin dense films. Max service temp: 450°C in air. Preferred for vacuum applications. Same treat rates as MoS2 in resin-bonded systems.
hBN Coatings — Best for Extreme High-Temp, Mold Release, Electrical Insulation
Metal casting mold release (aluminum, brass, zinc die casting). Furnace and kiln components (stable to 900°C+). Electrical component coatings (lubricating + insulating). White or light-colored coatings where dark MoS2/WS2 isn’t acceptable. Often applied without binder to hot molds (direct spray). Desilube Inc supplies NSF HX1 certified hBN for food-processing equipment coatings.
Blended Coatings
| Blend | Benefit |
|---|---|
| MoS2 + WS2 | EP strength + higher temp ceiling |
| MoS2 + hBN | EP performance + chemical resistance |
| WS2 + hBN | High-temp + electrical insulation |
| All three | Maximum performance envelope |
Why Surface-Modified Powders Matter
Raw MoS2, WS2, or hBN powder agglomerates in coating systems, causing film defects. Surface-modified powders from Powderful Solutions disperse uniformly in solvent-based, waterborne, and oil-based systems — producing denser, more consistent coating films.
FAQ
Q: What is the best solid lubricant for dry film coatings?
A: Depends on the application. MoS2 for general industrial and defense coatings. WS2 for PVD/aerospace and high-temp above 350°C. hBN for white coatings, electrical insulation, and extreme high-temp above 450°C.
Q: What particle size is best for dry film lubricant coatings?
A: 0.5–2 µm for resin-bonded coatings. Sub-micron (0.1–0.5 µm) for burnished films and PVD. Powderful Solutions offers multiple grades of all three.
Q: Can MoS2 and hBN be blended in a coating?
A: Yes — MoS2/hBN blends combine EP strength with high-temp stability and chemical resistance. Common in advanced industrial coatings.
Q: Do I need surface-modified powders for coating formulations?
A: Strongly recommended. Surface modification prevents agglomeration and improves particle-binder adhesion, resulting in more uniform, durable coating films.
Powderful Solutions supplies surface-modified MoS2, WS2, and hBN powders for dry film lubricant coatings, greases, and oils — powderfulsolutions.com | Food-grade hBN for processing equipment: desilubeinc.com
